DryLine Antenna ® Dehydrator, Low-pressure membrane, 19 in rack mountable, 2.0-5.0 psig, with discr

Data sheet

PDF

/pdfs/MOJAVE1A-24 .pdf

docs Y

y

specs Y

y

Includes

3/8 in polyethylene tubing - 90º elbow fitting - Male connector fitting - Needle valve - Power cord - Power cord connector lock - PTFE tape - Screws

Product Width

48.18 cm - 17.00 in

Net Weight

11.79 kg - 26.00 lb

gross weight, packed

17.73 kg - 39.09 lb

Product Depth, Packed

49.53 cm - 19.50 in

Product Height, Packed

52.71 cm - 20.75 in

Product Width, Packed

59.06 cm - 23.25 in

Product Height

22.23 cm - 8.75 in

Product Depth

25.40 cm - 10.00 in

Operating Temprature

-10 °C to +40 °C (+14 °F to +100 °F)

Dehydrator Type

Automatic Membrane

Volume Capacity, maximum

1699.00 L - 60.00 ft³

Power Cord

USA power cord

Mount Type

Floor - Rack - Shelf - Wall

Port Count

1

Port Type

3/8 in PE tube

Voltage

24 Vdc ±10% inverter

Power Consumption

204.0 W

Power Phase

Single

Suggested Curcuit Breaker Size

20 A

Voltage Type

dc

Dew Point

Better than -45 °C (-50 °F) at 95% RH at +40 °C (+104 °F)

Flow Rate

4.20 SLPM - 0.15 SCFM

Cut In Pressure

13.79 kPa - 2.00 psig

Alarm Type

Summary

Excess-Run Alarm

10 minutes, factory set

Low-Pressure Alarm

68 mbar - 7 kPa - 1 psig

Alarm Contact Rating

Form C dry contacts, 2 amps at 30 Vdc

Circuit Breaker Requirement

Electrical connections require separate circuits for dehydrator installation

Cut In/Out Pressure Type

factory set

High-Humidity Alarm

7.5% RH, factory set

Power-Fail Alarm

Loss of input power

Cut Out Pressure

34.47 kPa - 5.00 psig

Rack Type

EIA 19 in

Rack Units

5
